Products Range : Stailless Steel Hinges and Door & Window Fittings
Description Type Size
Stailless Steel Hinges and Door & Window Fittings PDF 708 KB

(Right Click and Save target As for Download PDF )



458 SS RC, Steel Supporting Hinges (OR) Offset Hinges - Handed Standard Cranked Knuckle
Size Length Open Width Sheet Thickness Holes for Screw No. PRS. in Inner Box PRS. in Outer Carton Approx. Wt. Per 10 Prs
(Kgs.)		 Pallet Qty in Prs.
80 80 2.50 7 5 80 3.140 3200

Finish Available : Mirror / Satin


105 SSBB, Stainless Steel Flush Hinges
Standard Knuckle, Two Ball Bearings And Button Tip Pin
Size Length Open Width Sheet Thickness Holes for Screw No. PRS. in Inner Box PRS. in Outer Carton Approx. Wt. Per 10 Prs
(Kgs.)		 Pallet Qty in Prs.
101 72 2.5 8 10 100 3.140 3200

Finish Available : Satin / Mirror


459SS, Stainless Steel Supporting Hinges
Standard Knuckle, Handed
Size Length Open Width Sheet Thickness Holes for Screw No. PCS. in Inner Box PCS. in Outer Carton Approx. Wt. Per 10 Prs
(Kgs.)		 Pallet Qty in Prs.
100 86 3.00 10 10 100 3.140 3200

Finish Available : Satin / Mirror


923SS, Stainless Steel Tower Bolt
Size  Length of Base Plate  Base Plate Width



 Shoot (Rod)Diameter Holes For Screw No. PCS. In Inner Box PCS. In Outer Carton Approx. Wt. Per 10 PCS. (Kgs.)
(MM)  (IN)
75 3 75 33 10 4 10 24 0.840
100 4 100 33 10 4 10 24 1.300
150 6 150 33 10 4 10 16 1.580
200 8 200 33 10 4 10 12 2.160
250 8 250 33 10 6 10 12 2.520
300 8 300 33 10 6 10 12 3.070

Finish Available : Polished, Satin


1256SS, Stainless Steel Aldrop
Size  Shoot (Rod) Diameter Sheet Thickness Length * Width of Handle PCS. In Inner Box PCS. In Outer Carton Approx. Wt. Per 10 PCS. (Kgs.)
(MM)  (IN)
200 8 14 2 148*40 5 12 5.320
250 10 14 2 148*40 5 12 6.020
300 12 14 2 148*40 5 12 6.430

Finish Available : Polished, Satin
